APC ProtectNet standalone surge protector for 10/100/1000 Base-T Ethernet lines
Overview
| Presentation | Protects an Ethernet data port from damaging surges. Compatible with Power over Ethernet (PoE) and 10/100/1000 Base-T networks. |
|---|
| Lead time | Usually in Stock |
|---|
Main
| Product or component type | Uninterruptible power supply (UPS) |
|---|
| Provided equipment | 15 cm network patch cable
User manual |
|---|
Physical
| Colour | Beige |
|---|
| Height | 10.4 cm |
|---|
| Width | 4.7 cm |
|---|
| Depth | 2.8 cm |
|---|
| Net weight | 0.05 kg |
|---|
| Mounting preference | No preference |
|---|
| Mounting mode | Not rack-mountable |
|---|
Conformance
| Standards | UL 497B |
|---|
Environmental
| Ambient air temperature for operation | -15…65 °C |
|---|
| Relative humidity | 0…95 % |
|---|
| Ambient air temperature for storage | -15…65 °C |
|---|
| Storage Relative Humidity | 0…95 % |
|---|
Surge Protection and Filtering
| Data line protected | 1-8 |
|---|
| Response time | 1 ns common mode |
|---|
| Common mode rejection | 0 dB |
|---|
| Peak current | 0.25 kAcommon mode
6.5 kAnormal mode |
|---|
Packing Units
| Unit Type of Package 1 | PCE |
|---|
| Number of Units in Package 1 | 1 |
|---|
| Package 1 Height | 10.4 cm |
|---|
| Package 1 Width | 2.9 cm |
|---|
| Package 1 Length | 9 cm |
|---|
| Package 1 Weight | 0.11 kg |
|---|
| SCC14 | 10731304226731 |
|---|
